Double Offset Butterfly Valves

Butterfly Valve

Size: 2"~160"（DN50~DN4000）

Pressure Rating: ASME CLASS 150~600

Body material: Carbon steel, Stainless steel, Special Alloy etc.

End connection: Wafer, Lug, Flange etc.

Operation: Manual, Pneumatic, Electric ect.


Inquiry Now
Description

JUDU Double Offset Butterfly Valves comply to API609 standard, its structural feature is that the valve stem axis is offset from both the center of the butterfly plate and the center of the valve body channel. This design allows the butterfly plate to quickly separate from the valve seat when the valve is opened, greatly eliminating unnecessary excessive squeezing and scraping between the butterfly plate and the valve seat, thereby reducing the opening resistance, reducing wear, and increasing the life of the valve seat.
